CWC2P50-FGG484I FPGA

CWC2P50-FGG484I is a domestic FPGA from the CWC 2P series. It is designed for programmable logic applications and can be evaluated as an alternative to AMD Xilinx XC7S50 devices in projects looking for a domestic FPGA solution.

For engineers searching for an XC7S50 replacement, the CWC2P50-FGG484I is one of the models that can be considered for further hardware and FPGA design evaluation.

The device uses an FGG484 package, while the model designation ends with I, which is identified in publicly available third-party information as an industrial-grade version.

XC7S50-1FGGA484I and XC7S50-2FGGA484I Replacement

CWC2P50-FGG484I is listed as an alternative corresponding to the following AMD Xilinx FPGA models:

XC7S50-1FGGA484I

XC7S50-2FGGA484I

Both reference models use the FGG484 package.

This makes the package one of the key points to examine when evaluating CWC2P50-FGG484I for an existing XC7S50-based design.

However, an FPGA replacement should not be determined only by the package. Engineers should also compare the pin assignment, logic resources, I/O resources, memory, DSP resources, clocking, power requirements, configuration method, and development environment.

CWC2P50-FGG484I Package

The FGG484 designation refers to a 484-pin fine-pitch BGA package.

For an XC7S50 replacement project, package information is important because the original PCB may already have been designed around the XC7S50 FGG484 package.

Before changing the FPGA, engineers should verify the physical package dimensions, ball arrangement, pin functions, power pins, I/O assignment, and PCB routing requirements.

Even when two devices use a similar package, this does not automatically mean that the devices are pin-to-pin compatible.

CWC2P50-FGG484I FPGA Resources

Publicly available third-party descriptions indicate that CWC2P50-FGG484I belongs to the approximately 50K logic-element class.

Some third-party sources describe the device with around 52,160 logic elements, approximately 2.7 Mbit of BRAM, and 120 DSP resources.

Other published information indicates around 250 user I/O resources and multiple clock management resources.

These figures should be treated as reference information and verified against the official technical documentation for the exact device before engineering use.

Industrial-Grade CWC2P50-FGG484I

The I suffix is described by third-party sources as an industrial-grade version.

Some public descriptions associate the industrial-grade device with a temperature range of approximately -40°C to +100°C.

For industrial applications, temperature requirements should be checked carefully against the official specification of the exact device. The operating environment, system thermal design, power consumption, and reliability requirements should all be considered during FPGA selection.

CWC 2P FPGA Series

CWC2P50-FGG484I belongs to the CWC 2P series of domestic FPGA products.

Public information about CWISE indicates that its business covers FPGA products, eFPGA IP, data acquisition cards, FPGA system application solutions, and SoC design services.

The CWC 2P series can therefore be considered in applications that require programmable logic and customized FPGA-based system designs.

Applications

CWC2P50-FGG484I can be evaluated for a range of FPGA applications, including industrial control, embedded systems, communication equipment, data acquisition, signal processing, and customized electronic systems.

For products currently based on XC7S50 devices, the CWC2P50-FGG484I can be included in a domestic FPGA replacement evaluation.

The actual suitability depends on the resource requirements and architecture of the target system.

What to Check When Replacing XC7S50

Replacing an XC7S50-1FGGA484I or XC7S50-2FGGA484I with another FPGA requires a detailed engineering evaluation.

The main items to check include:

Package and physical dimensions

Pin assignment

Logic resources

Block RAM

DSP resources

User I/O

Clock resources

Power supply requirements

Configuration interface

Operating temperature

FPGA development tools

IP compatibility

Existing FPGA logic design

System-level performance

These factors are particularly important when an existing PCB and FPGA design need to be migrated.

CWC2P50-FGG484I as an XC7S50 Alternative

For engineers searching for an XC7S50 replacement, CWC2P50-FGG484I provides a domestic FPGA option that can be evaluated against XC7S50-1FGGA484I and XC7S50-2FGGA484I.

Its FGG484 package, approximately 50K logic-resource class, industrial-grade option, memory resources, DSP resources, and user I/O make it relevant for FPGA localization and alternative-component evaluation.

The replacement should be confirmed through detailed datasheet comparison, hardware testing, FPGA design migration, and system validation before production.
