Custom FR4 Metal Detector & BMS PCB Manufacturer

Custom FR4 Metal Detector and BMS PCB

This custom FR4 PCB is designed for metal detector systems and battery management applications. The board is manufactured with FR4 material and can be customized according to Gerber files, BOM and functional requirements.

The manufacturing service covers PCB fabrication as well as one-stop PCBA assembly for prototype, small-batch and mass production.

FR4 Circuit Board Manufacturing

FR4 is used as the base material for both metal detector and BMS circuit boards. The material provides electrical insulation, heat resistance and mechanical stability for electronic equipment.

The PCB can be manufactured from 1 to 8 layers, with copper thickness from 0.5oz to 3oz depending on the circuit and current requirements.

Metal Detector PCB

The metal detector PCB is designed for control circuits that require stable signal processing and high sensitivity.

PCB routing and grounding can be optimized for low-noise operation and stable signal transmission. The board is suitable for metal detector control systems and security inspection equipment.

BMS Circuit Board

The BMS PCB is designed for battery management and power control applications. The source page recommends 2oz copper for BMS designs where additional current-carrying capability is required.

Depending on the battery system and circuit design, 2 to 6 layers can be used, with immersion gold or OSP available for the surface finish.

PCB Precision and Signal Stability

The PCB manufacturing process supports 4mil minimum line width and spacing. Accurate pads, stable traces and controlled circuit routing help meet the requirements of electronic sensing and battery management applications.

For metal detector designs, particular attention can be given to trace routing and ground design to help maintain signal sensitivity and reduce unwanted interference.

PCB Surface Finishes

Available surface finishes include HASL, lead-free HASL, immersion gold and OSP.

The finish can be selected according to the PCB design, assembly process and connection requirements.

One-Stop PCBA Assembly

The PCB can be supplied as a bare board or combined with PCBA manufacturing. SMT, DIP, component sourcing, AOI inspection and functional testing are available for custom projects.

This allows customers to use one production process from PCB fabrication through assembled board delivery.

OEM and Custom PCB Manufacturing

Customers can provide Gerber files, BOM and functional requirements for custom production. Prototype, small-batch and mass production are supported.

Standard FR4 PCB prototypes are typically listed at 3-5 working days, with faster quick-turn options available depending on the project.

Metal Detector and BMS PCB Applications

Metal Detector Control Boards

FR4 control boards for metal detection equipment requiring stable signal processing and sensitive detection circuits.

Security Inspection Equipment

PCBs for security inspection and detection systems used in electronic security equipment.

Battery Management Systems

BMS circuit boards for battery monitoring, management and protection functions.

Power Management Modules

Custom PCBs for power management and related electronic control circuits.

Industrial Sensing Devices

Circuit boards for industrial sensing equipment and electronic detection systems.

Technical Specifications

• Board Material: FR4

• Board Type: Metal Detector PCB, BMS Circuit Board

• Layer Count: 1-8 layers

• Copper Thickness: 0.5oz-3oz

• Minimum Line/Space: 4mil/4mil

• Surface Finish: HASL, Lead-Free HASL, Immersion Gold, OSP

• Assembly: SMT, DIP

• Testing: AOI, Functional Testing

• Input Files: Gerber, BOM

• Production: Prototype, Small Batch, Mass Production

• Prototype Lead Time: 3-5 working days

• Service: OEM Custom PCB and One-Stop PCBA

Custom Metal Detector and BMS PCBA

For projects requiring assembled boards, the PCB can be combined with component sourcing, SMT and DIP assembly, AOI inspection and functional testing.

The manufacturing process can be adapted to the electrical requirements of metal detection equipment or battery management systems, from prototype boards to production quantities.
